In order to protect vehicle occupants in the event of a so-called thermal runaway, in which the battery heats up quickly and uncontrollably and, in the worst case, ignites or explodes, fire protection materials and components such as flame shields are among the most effective methods.
Autoneum’s E-Fiber flame shields excel not only with their ability to withstand extreme temperatures, but also with their low weight and mechanical strength. In contrast to alternative standard products, which often consist of heavy and brittle mineral materials such as mica, the innovative shields based on E-Fiber are lightweight, stiff and stable. Due to the moldability of the material, the shields also ensure excellent battery coverage and design flexibility. Thanks to the possibility of manufacturing components with complex 3D shapes, there is also the potential to integrate an additional function to guide hot gases away from the battery. The shields are based on a composite material made of reinforcing fibers and resin, which are formed into thin layers of one to two millimeters. The heat resistance of up to 1400°C and the mechanical strength of the material significantly increase the shields’ resistance to high temperatures, but also hot particle abrasion and gas pressure. Moreover, the fibers provide the part’s non-conductive and insulating properties, which are necessary for the battery system’s electrical insulation and thermal safety.
The E-Fiber flame shields can be installed between the battery cells and the battery cover or the vehicle floor and contribute significantly to increasing the safety of vehicle occupants in the event of a battery thermal runaway. They thus offer a lightweight, safe and geometrically adaptable alternative to standard flame shields on the market. In addition, the composite shields are completely risk-free from a compliance perspective. This is in contrast to mica-based products, which can prove problematic in terms of responsible sourcing.
