Schaeffler iARC Intelligent Active Roll Control

dsc02058 2 orig

On-board electric system: 12 V or 48 V
Dimensions: 90×300 / 392 mm (without stabilizer arms)
Weight: Approx. 12 kg (without stabilizer arms and cable harness)

dsc02057 orig

Max. torque: 900 Nm (12 V) and 1400 Nm (48 V)
Operational angle of rotation: +/- 30 degrees
Step response time: 900 Nm within 200 ms
Torque accuracy: 40 Nm (4%)
Datatransmission: FlexRay and CAN ​
