PEM stack module with integrated system functionalities based on metallic bipolar plates with an electric output of 400 kWel.
Characteristics
- Hydrogen-air operation
- Liquid-cooled
- Pressure operation up to 2.8 bara
- Rated power of 400 kWel at 900 A
- IP6k9k / IP67 housing with EMC shielding
- Compact integrated cell voltage monitoring (CVM)
- Integrated water separator, media conditioning and monitoring as well as media control
- Robust sensors and actuators acc. to automotive standards
The PEMFC stack module NM20 is designed for applications with high power and high efficiency requirements.
